Preliminary Filter
Vorfilter 12 cm
Item no.:4173801EAN: 4006825549188
einhell-accessory-preliminary-filter-4173801-productimage-001
einhell-accessory-preliminary-filter-4173801-productimage-001
Preliminary Filter

Vorfilter 12 cm

Item no.: 4173801 EAN: 4006825549188
  • Robust, transparent filter housing
  • Removable, 0.2 mm-mesh fine filter
  • Bleed Screw
  • External 33.3 mm (1") brass thread
  • 1x connector nipple with 33.3 mm (1") external / 42 mm (1 1/4") internal threads
  • 1x double nipple with 33.3 mm (1") external thread
  • Max. recommended working pressure: 5.5 bar
  • Pumps liquids up to 35 °C
  • Max. flowrate: 4,000 L/h
See more information
Show less information
einhell-accessory-preliminary-filter-4173801-productimage-001
Article description

Fine-meshed protection for pumps against harmful dirt: the Original Einhell 12 cm pre-filter is a robust protective device to prevent garden pumps, domestic water systems and automatic water pumps from being damaged by dirt. The integrated 0.2 mm-mesh fine filter is washable, easy to remove and easy to change. The pre-filter has a bleed screw as well as a strong and durable brass internal thread (33.3 mm) and a transparent filter housing. The maximum recommended working pressure is 5.5 bar, and the pre-filter is suitable for a maximum flow rate of 4000 litres per hour. The temperature of the liquid flowing through must not exceed 35 °C. The kit includes a double nipple with a 33.3 mm (1") external threaded and an adapter fitting with 33.3 mm (1") external / 42 mm (1 1/4") internal threads. The filter insert is easy to remove and rinse with clear water for cleaning. The fine filter fabric inside must not be damaged. The time between cleanings depends on how dirty the water is. The pre-filter is the ideal addition for surface pumps that do not have an internal pre-filter.

See more information
Show less information

Technical data

Filter length12 cm
Material filter housingPlastic
Max. Working pressure5.5 bar
Max. delivery rate4000 l/h
Max. water temperature35 °C
Mesh size of filter0.2 mm
Pressure connection type33,3 mm (R1 IG)
Suction connection type33,3 mm (R1 IG)
Thread pressure connection materialBrass
Thread suction connection materialBrass
